Electrical Specifications
Rated Capacity (0.5C, 25°C): 100Ah
Cycle Life (0.5C/1C, 25℃): 5000 Cycles (80% DOD, 80% EOL)
Charging Parameters
Maximum Continuous Charge Current: 30A
Discharging Parameters
Maximum Continuous Discharge Current: 100A
Peak Discharge Current: 200A@10s
Temperature Parameters
Operation Temperature Range: Charge: 32°F to 131°F / 0°C to 55°C Discharge: -4°F to 140°F / -20°C to 60°C
Storage Temperature Range: -13°F to 149°F / -25°C to 65°C
Operation Relative Humidity: 10% to 95%
Mechanical Specifications
Dimension (L x W x H): 20.47 x 13.19 x 5.91 in / 520 x 335 x 150 mm
Weight: 72.75 lbs. / 33 kg
Terminal Bolt Size: M8 x 1.25 x 15 mm
Accessories
Long Terminal Bolts (2): M8
Certifications
MSDS, UN38.3, FCC, PSE, CE, UKCA, IEC62619: YES
Warranty
Material and Workmanship Warranty: 5 Years
